INTRODUCING THE FUTURE OF MOTORSPORTS

MEV Racing with FPV on-road RC model race cars controlled by you in the Sim Rig – we define the technology as Telemetric Reality (TR)

Imagine stepping into the driver’s seat of a miniature racing machine, gripping a steering wheel and paddles that respond to your every move, all while experiencing the exhilaration of over 200 MPH visual speed racing through a first-person perspective. As the future of motorsports continues to evolve, MEV Racing stands at the forefront, paving the way for a new era of excitement and innovation in the world of racing.

- FEATURES -
• MEV Telemetric Reality Race Vehicle Control System is a vital sub-system of the 1st proprietary commercial production race system in the world (currently the 5th generation) that brings the real race car driving experience to life through the ultimate fusion of FPV, On-Road RC, and Sim Rig technologies
• Proprietary product developed by INNOEC Technology in collaboration with MEV Official Race Sponsors, Radio / Micro Scale Race Car Technology Partner Turbo Racing (for Radio Control sub-system optimization) and Sim Rig Technology Partner PXN (for Control Mechanics sub-system optimization)
• Realistic racing steering wheel with non-slip grip rubber surface for simulated track racing experience
• Responsive 270° rotation angle simulating professional race car (from Go-Kart to Formula 1) for precise steering (steering proportion adjustable)
• Rigid structure for performance handling
• Control system can be installed on a simple table (with fixture and pedals on the floor) as well as mounting on most professional racing simulator seats for realistic driving experience
• High strength centering spring mechanism provides adaptive feedback when driving with FPV goggles
• Easily accessible quick adjustment side panel for driver to adjust parameters when driving with FPV goggles
• 4 surface push buttons, 2 paddle shifters, and 2 feedback vibration motos inside for programing functionality and feedback (compatible with all open-source hardware platforms)
• Adaptive 2-stage linear foot pedals with torsion spring for precision control
• Fully adjustable control functions including Trim, Dual Rate, EPA, Exponential, Reverse, ABS, Climbing Mode, SVC, Fail-Safe, etc.
• Store up to 15 sets of setting for different drivers / vehicles with respective names / codes
• One TR 7-Channel Control Receiver (MEV-19006-R) included and pre-bound for ease of use on any RC cars (boats)

- IN THE BOX -
Telemetric Reality (TR) Race Vehicle Control Console * 1
TR Race Vehicle Control Pedals * 1
TR 7-Channel Control Receiver * 1
TR Table Fixture Bolt & Support * 1
TR Table Fixture Rack * 1

- SPECIFICATIONS -
Number of Channels: 7
Control Console Input Voltage: 6V DC - 1.5V AA*4 (not included) or 2S LiPo Battery (sold separately)
Remote Control Distance: 120M
Frequency Range: 2405-2478GHz
Waveband Width: 1MHz
Waveband Number: 74
Transmit Power Level: <20dBm
Modulation Mode: GFSK
Channel Delay: <10ms
Low-Voltage Warning: AA Battery: <4.4V, 2S LiPo Battery: <7.2V
Antenna Length: 200mm
Throttle Level Indicator: LED*3
Working Current: 50mA
Channel Data: Neutral: 1500μs, Range: 800-2200μs
Control Console Weight: 1672g
Control Console Dimension: 300*240*270mm
Control Pedals Weight: 800g
Control Pedals Dimension: 300*240*100mm
Certificate: FCC, CE, ROHS
